Semi-rigid, 50 Ohm, 40 GHz, 125°C, ø2.2 mm, Copper/Tin plated, M17

Name: Semi-rigid, 50 Ohm, 40 GHz, 125°C, ø2.2 mm, Copper/Tin plated, M17
SKU: 22810175

Product number 22810175

Identifier SR_86_TP_M17_COIL

Variation: Coil

Choose a variant

Coil

Key features

Choose a variant

Coil

Construction

Component	Material	Detail	Diameter
Centre conductor	Steel, Copper + Silver plated	Wire	0.51 mm
Dielectric	PTFE (Polytetrafluoroethylene)		1.68 mm
Outer conductor	Copper, Tin plated	Tube, 100%	2.2 mm

Electrical data

Mechanical data

Environmental data

Product code	SR_86_TP_M17
Cable family	Semi-rigid: Semi-rigid, formable microwave cables
Available as assembly only	No
Cable group	Y3

Impedance	50 Ω +/-1.5Ω
Operating frequency	≤ 40 GHz
Capacitance	105 pF/m
Velocity of signal propagation	69.5 %
Signal delay	4.8 ns/m
Screening effectiveness	120 dB at frequency 0.1 GHz ... 20GHz
Insulation resistance	100000000 MΩ*m
Operating Voltage (at sea level)	≤ 1.5 kVrms
Noise level	10 mV

Weight	approx. 23.5 g/m
Static bending radius	≥ 3.18 mm
