Twinax, RG108, 78 Ohm, 1 GHz, 85°C, ø6 mm, PVC jacket

Name: Twinax, RG108, 78 Ohm, 1 GHz, 85°C, ø6 mm, PVC jacket
SKU: 22510031
Availability: InStock

Product number 22510031

Identifier RG_108_A/U

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
1st Centre conductor	Copper	Strand-07	0.93 mm
1st Dielectric	PE (Polyethylene)		2 mm
2nd Centre conductor	Copper, Tin plated	Strand-07	0.93 mm
2nd Dialectric	PE (Polyethylene)		2 mm
Outer conductor	Copper, Tin plated	Braid, 88%	4.6 mm
Jacket	PVC II (low migration)	RAL 9005 - bk	6 mm	HUBER+SUHNER RG 108 A/U 78 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Impedance	78 Ω +/-7Ω
Operating frequency	≤ 1 GHz
Capacitance	65 pF/m
Velocity of signal propagation	66 %
Signal delay	5 ns/m
Insulation resistance	1000000000 MΩ*m
Operating Voltage (at sea level)	≤ 1 kVrms
Test voltage (50 Hz/1 min)	≤ 2 kVrms
