Hand formable (RG402) 50Ohm 33GHz, 85°C, ø4.47mm LSFH jacket

Name: Hand formable (RG402) 50Ohm 33GHz, 85°C, ø4.47mm LSFH jacket
SKU: 84003502
Availability: InStock

Product number 84003502

Identifier SUCOFORM_141_CU_LSFH-01

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Wire	0.95 mm
Dielectric	PTFE (Polytetrafluoroethylene)		2.95 mm
Outer conductor	Copper, Tin plated	Tin soaked braid, 100%	3.58 mm
Jacket	LSFH (modified polyethylene)	RAL 2003 - or	4.47 mm +/- 0.07 mm	HUBER+SUHNER SUCOFORM 141 CU LSFH-01 50 Ohm (PA no.)

Electrical data

Mechanical data

Environmental data

Product code	SUCOFORM_141_CU_LSFH-01
Cable family	Sucoform: Formstable, hand-formable alternatives to semi-rigid microwave cables
Available as assembly only	No
Cable group	Y12

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 33 GHz
Capacitance	92 pF/m
Velocity of signal propagation	71 %
Signal delay	4.7 ns/m
Screening effectiveness	100 dB at frequency 0.1 GHz ... 4GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	25 Ω/km
Outer conductor resistance	18 Ω/km
Operating Voltage (at sea level)	≤ 1.9 kVrms
Test voltage (50 Hz/1 min)	≤ 5 kVrms
