RG178 LSFH, 50 Ohm, 3 GHz, 105°C, ø1.84 mm, RADOX® jacket

RG178 LSFH, 50 Ohm, 3 GHz, 105°C, ø1.84 mm, RADOX® jacket

Product number 85183340

Identifier ENVIROFLEX_178-AM

Variation: Missing product short name

General Information

Key features

Halogen free alternative to RG cables
Ozone, UV and weathering resistance
Bus qualified

Specifications

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper + Silver plated	Strand-07	0.305 mm
Dielectric	SPEX (Crosslink Foam PE)		0.82 mm
Outer conductor	Copper, Silver plated	Braid, 95%	1.27 mm
Jacket	RADOX	RAL 5010 - bl	1.84 mm +/- 0.07 mm	HUBER+SUHNER ENVIROFLEX 178-AM 50 Ohm (production order number)

Electrical data

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 3 GHz
Capacitance	94.5 pF/m
Velocity of signal propagation	70.7 %
Signal delay	4.71 ns/m
Screening effectiveness	40dB
Insulation resistance	10000000 MΩ*m
Inner conductor resistance	747 Ω/km
Outer conductor resistance	50 Ω/km
Operating Voltage (at sea level)	≤ 1 kVrms
Voltage Rating UL	300 V
Phase vs temperature	8400 ppm at temperature
Phaase vs bending	0.7 °/GHz
Test voltage (50 Hz/1 min)	≤ 2 kVrms

Mechanical data

Environmental data
