High-flexible, 50 Ohm, 6 GHz. 165°C, 1.00mm, PFA jacket

Name: High-flexible, 50 Ohm, 6 GHz. 165°C, 1.00mm, PFA jacket
SKU: 85117373

Product number 85117373

Identifier Miniflex_36_LA

Variation: -

Key features

Construction

Component	Material	Detail	Diameter
Centre conductor	Copper, Silver plated	Wire
Dielectric	Low density fluorine polymer
Outer conductor	Copper, Silver plated	Braid, 88.7%
Jacket	Low density fluorine polymer	RAL 5015 - bl	1 mm +/- 0.1 mm

Electrical data

Mechanical data

Environmental data

Product code	Miniflex_36_LA
Available as assembly only	Yes

Impedance	50 Ω +/-4Ω
Operating frequency	≤ 6 GHz
Capacitance	86.6 pF/m
Velocity of signal propagation	76.2 %
Signal delay	4.4 ns/m
Screening effectiveness	≥ 35 dB at frequency 0.1 GHz ... 6GHz
Insulation resistance	≥ 1000000 MΩ*m
Inner conductor resistance	≤ 386 Ω/km
Operating Voltage (at sea level)	≤ 0.15 kVrms
Test voltage (50 Hz/1 min)	≤ 0.3 kVrms

Weight	approx. 2.5 g/m
Static bending radius	≥ 1.5 mm

Operation temperature	-55 °C ... 165 °C
Fire characteristics	contains halogene
