Low-loss, 50 Ohm, 6 GHz, 85°C, ø6.17 mm, LSFH jacket

Name: Low-loss, 50 Ohm, 6 GHz, 85°C, ø6.17 mm, LSFH jacket
SKU: 85069656
Availability: InStock

Product number 85069656

Identifier SPUMA_240-FR-AM

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper	Wire	1.42 mm
Dielectric	SPE (Foamed Polyethylene)		3.82 mm
Outer conductor	Aluminum / PES	longitudinal Foil, 100%	3.94 mm
Outer conductor	Copper, Tin plated	Braid, 94%	4.52 mm
	LSFH (modified polyethylene)	RAL 9005 - bk	6.17 mm +/- 0.1 mm	HUBER+SUHNER SPUMA 240-FR-AM 50 Ohm (production order number)

Electrical data

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 6 GHz
Capacitance	78.9 pF/m
Inductance	0.2 µH/m
Velocity of signal propagation	82.6 %
Signal delay	4.05 ns/m
Screening effectiveness	90 dB at frequency 6GHz
Insulation resistance	1000000 MΩ*m
Inner conductor resistance	10.89 Ω/km
Outer conductor resistance	9.35 Ω/km
Operating Voltage (at sea level)	≤ 0.9 kVrms
Test voltage (50 Hz/1 min)	≤ 1.5 kVrms

Mechanical data

Environmental data

Product code	SPUMA_240-FR-AM
Cable family	Spuma: Flexible, low-loss RF cables
Available as assembly only	No
Cable group	X28

Operation temperature	-40 °C ... 85 °C
Installation temperature	-20 °C ... 60 °C
Fire characteristics	free of halogenes, acc. standard IEC 60754
