RG316D LSFH, 50 Ohm, 8 GHz, 105°C, ø3.2 mm, RADOX® jacket

Name: RG316D LSFH, 50 Ohm, 8 GHz, 105°C, ø3.2 mm, RADOX® jacket
SKU: 85023719
Availability: InStock

Product number 85023719

Identifier RADOX_RF_316_D

Variation: -

Key features

How to use it

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper + Silver plated	Strand-07	0.54 mm
Dielectric	SPEX (Crosslink Foam PE)		1.53 mm
Outer conductor	Copper, Silver plated	Braid, 96%	1.99 mm
Outer conductor	Copper, Silver plated	Braid, 90%	2.44 mm
Jacket	RADOX EM104	RAL 9005 - bk	3.2 mm +/- 0.1 mm	HUBER+SUHNER RADOX_RF_316_D 50 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Product code	RADOX_RF_316_D
Cable family	RADOX RF: Highly flame retardant LSFH alternatives to RG cables
Cable group	U4

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 8 GHz
Capacitance	94.5 pF/m
Velocity of signal propagation	70.1 %
Signal delay	4.72 ns/m
Screening effectiveness	≥ 70 dB at frequency 0 GHz ... 6GHz
Insulation resistance	< 10000000 MΩ*m
Operating Voltage (at sea level)	≤ 1.5 kVrms
Voltage Rating UL	300 V
Test voltage (50 Hz/1 min)	≤ 3 kVrms

Operation temperature	-40 °C ... 105 °C
Installation temperature	-20 °C ... 60 °C
Flame propagation standard	EN 60332-1-2 EN 50305, 9.1.2 UL 1581 § 1100 CFR/JAR/CS Part 25 Appendix F
Fire characteristics	free of halogenes, acc. standard IEC 60754
Smoke test	EN 61034-2
UV resistance	ISO 4892-2A
