RG179 LSFH, 75 Ohm, 3 GHz, 105°C, ø2.8 mm, RADOX® jacket

Name: RG179 LSFH, 75 Ohm, 3 GHz, 105°C, ø2.8 mm, RADOX® jacket
SKU: 85023705
Availability: InStock

Product number 85023705

Identifier RADOX_RF_179

Variation: -

Key features

How to use it

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper + Silver plated	Strand-07	0.305 mm
Dielectric	SPEX (Crosslink Foam PE)		1.55 mm
Outer conductor	Copper, Silver plated	Braid, 94%	2 mm
Jacket	RADOX EM104	RAL 9005 - bk	2.8 mm +/- 0.1 mm	HUBER+SUHNER RADOX_RF_179 75 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Product code	RADOX_RF_179
Cable family	RADOX RF: Highly flame retardant LSFH alternatives to RG cables
Available as assembly only	No
Cable group	U5

Impedance	75 Ω +/-3Ω
Operating frequency	≤ 3 GHz
Capacitance	63 pF/m
Velocity of signal propagation	69.7 %
Signal delay	4.78 ns/m
Screening effectiveness	≥ 40 dB at frequency 0.01 GHz ... 1GHz
Insulation resistance	10000000 MΩ*m
Operating Voltage (at sea level)	≤ 1 kVrms
Test voltage (50 Hz/1 min)	≤ 2 kVrms

Operation temperature	-40 °C ... 105 °C
Installation temperature	-20 °C ... 60 °C
Flame propagation standard	EN 60332-1-2 EN 50305, 9.1.2 UL 1581 § 1100
Fire characteristics	free of halogenes, acc. standard IEC 60754
Smoke test	EN 61034-2
UV resistance	ISO 4892-2A
