Flexible, 50 Ohm, 100 GHz, 165°C, ø1.74 mm, FEP jacket

Name: Flexible, 50 Ohm, 100 GHz, 165°C, ø1.74 mm, FEP jacket
SKU: 85006318

Product number 85006318

Identifier MULTIFLEX_53-02

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Wire	0.31 mm
Dielectric	PTFE (Polytetrafluoroethylene)		0.99 mm
Outer conductor	Copper, Silver plated	Wrapped foil, 100%	1.12 mm
Outer conductor	Copper, Silver plated	Wrapped foil, 100%	1.25 mm
Outer braid	Copper, Silver plated	Braid, 93%	1.5 mm
Jacket	FEP (Fluorinated ethylene propylene)	RAL 5015 - bl	1.74 mm +/- 0.05 mm	HUBER+SUHNER MULTIFLEX 53-02 (production order number)

Electrical data

Mechanical data

Environmental data

Product code	MULTIFLEX_53-02
Cable family	Multiflex: Flexible alternatives to semi-rigid microwave cables
Available as assembly only	Yes
Cable group	Y18

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 100 GHz
Capacitance	95 pF/m
Velocity of signal propagation	70 %
Signal delay	4.8 ns/m
Screening effectiveness	≥ 90 dB at frequency 0.1 GHz ... 18GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	350 Ω/km
Operating Voltage (at sea level)	≤ 0.75 kVrms
Test voltage (50 Hz/1 min)	≤ 1.5 kVrms
