Low-loss, 50 Ohm, 6 GHz, 85°C, ø10.25 mm, LSFH jacket

Name: Low-loss, 50 Ohm, 6 GHz, 85°C, ø10.25 mm, LSFH jacket
SKU: 84040210
Availability: InStock

Product number 84040210

Identifier SPUMA_400-FR

Variation: -

Key features

How to use it

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Aluminium / Copper	Wire	2.74 mm
Dielectric	SPE (Foamed Polyethylene)		7.24 mm
Outer conductor	Aluminum / PES	longitudinal Foil, 100%	7.4 mm
Outer conductor	Copper, Tin plated	Braid, 78%	8.15 mm
Jacket	LSFH (modified polyethylene)	RAL 9005 - bk	10.25 mm +/- 0.1 mm	HUBER+SUHNER SPUMA 400-FR 50 Ohm (UL logo) AWM Style 1354 (production order number)

Electrical data

Mechanical data

Environmental data

Product code	SPUMA_400-FR
Cable family	Spuma: Flexible, low-loss RF cables
Available as assembly only	No
Cable group	U30

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 6 GHz
Capacitance	78 pF/m
Inductance	0.2 µH/m
Velocity of signal propagation	85 %
Signal delay	3.9 ns/m
Screening effectiveness	90 dB at frequency 6GHz
Insulation resistance	1000000 MΩ*m
Inner conductor resistance	4.75 Ω/km
Operating Voltage (at sea level)	≤ 1.6 kVrms
Voltage Rating UL	30 V
Test voltage (50 Hz/1 min)	≤ 3 kVrms

Operation temperature	-40 °C ... 85 °C
Installation temperature	-20 °C ... 60 °C
Flame propagation standard	UL 1581 § 1100 UL 1581 § 1090 IEC 60332-3-24 EN 60332-1-2
Fire characteristics	free of halogenes, acc. standard IEC 60754
Smoke test	EN 61034-2
Cold bend test	MIL-C-17 § 4.8.19
UV resistance	ISO 4892-2A
