RG178 LSFH, 50 Ohm, 3 GHz, 105°C, ø1.84 mm, RADOX® jacket

Name: RG178 LSFH, 50 Ohm, 3 GHz, 105°C, ø1.84 mm, RADOX® jacket
SKU: 84032838

Product number 84032838

Identifier ENVIROFLEX_178-01

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper + Silver plated	Strand-07	0.305 mm
Dielectric	SPEX (Crosslink Foam PE)		0.82 mm
Outer conductor	Copper, Silver plated	Braid, 95%	1.27 mm
Outer conductor
Jacket	RADOX	RAL 9005 - bk	1.84 mm +/- 0.07 mm	HUBER+SUHNER ENVIROFLEX 178-01 50 Ohm (UL logo) AWM Style 3651 (production order number)

Electrical data

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 3 GHz
Capacitance	94.5 pF/m
Velocity of signal propagation	70.7 %
Signal delay	4.71 ns/m
Screening effectiveness	40 dB at frequency 0.03 GHz ... 3GHz
Insulation resistance	10000000 MΩ*m
Inner conductor resistance	747 Ω/km
Operating Voltage (at sea level)	≤ 1 kVrms
Voltage Rating UL	300 V
Phase vs temperature	8400 ppm at temperature -40 ... 100°C
Phaase vs bending	0.7 °/GHz
Test voltage (50 Hz/1 min)	≤ 2 kVrms

Mechanical data

Environmental data

Product code	ENVIROFLEX_178-01
Cable family	Enviroflex: LSFH alternatives to RG cables
Available as assembly only	No
Cable group	U1

Operation temperature	-40 °C ... 105 °C
Installation temperature	-20 °C ... 60 °C
Flame propagation standard	UL 1581 § 1100
Fire characteristics	free of halogenes, acc. standard IEC 60754
Ageing test	MIL-C-17 § 4.8.16
Cold bend test	MIL-C-17 § 4.8.19
UV resistance	IEC 60068-2-5, proc. C
Solar radiation	IEC 60068-2-5, proc. C
