RG316 LSFH, 50 Ohm, 3 GHz, 105°C, ø2.54 mm, RADOX®jacket,

Name: RG316 LSFH, 50 Ohm, 3 GHz, 105°C, ø2.54 mm, RADOX®jacket,
SKU: 84027942

Product number 84027942

Identifier ENVIROFLEX_316-03

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper + Silver plated	Strand-07	0.54 mm
Dielectric	SPEX (Crosslink Foam PE)		1.53 mm
Outer conductor	Copper, Silver plated	Braid, 99%	1.99 mm
Jacket	RADOX	RAL 9005 - bk	2.54 mm +/- 0.07 mm	HUBER+SUHNER ENVIROFLEX 316-03 50 Ohm (UL logo) AWM Style 3651 (production order number)

Electrical data

Mechanical data

Environmental data

Product code	ENVIROFLEX_316-03
Cable family	Enviroflex: LSFH alternatives to RG cables
Available as assembly only	No
Cable group	U2

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 3 GHz
Capacitance	94.5 pF/m
Velocity of signal propagation	70.7 %
Signal delay	4.71 ns/m
Operating Voltage (at sea level)	≤ 1.5 kVrms
Voltage Rating UL	300 V
Test voltage (50 Hz/1 min)	≤ 3 kVrms

Operation temperature	-40 °C ... 105 °C
Installation temperature	-20 °C ... 60 °C
Flame propagation standard	UL 1581 § 1100
Fire characteristics	free of halogenes, acc. standard IEC 60754
Ageing test	MIL-C-17 § 4.8.16
Cold bend test	MIL-C-17 § 4.8.19
UV resistance	IEC 60068-2-5, proc. C
