Low-loss, Armoured, 50 Ohm, 2GHz, 85°C, ø15.7mm, LSFH jacket

Name: Low-loss, Armoured, 50 Ohm, 2GHz, 85°C, ø15.7mm, LSFH jacket
SKU: 23023566
Availability: InStock

Product number 23023566

Identifier S_07262_BD-AH

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Strand-07	2.82 mm
Dielectric	SPE (Foamed Polyethylene)		7.38 mm
Outer conductor	Copper, Silver plated	Braid, 96%	8 mm
Outer conductor	Copper	Wrapped foil, 100%	8.1 mm
Outer conductor	Copper, Tin plated	Braid, 93%	9 mm
Jacket	LSFH (modified polyethylene)	RAL 9005 - bk	10.8 mm +/- 0.15 mm
Armour	Multi-end: Steel - zinc plated	Braid, 85%
Jacket	LSFH (modified polyethylene)	RAL 9005 - bk	15.7 mm +/- 0.35 mm	HUBER+SUHNER S 07262 BD AH 50 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Product code	S_07262_BD-AH
Cable family	S: Low loss RF cables with foam PE dielectrics
Available as assembly only	No
Cable group	S32

Impedance	50 Ω +/-1Ω
Operating frequency	≤ 2 GHz
Capacitance	82 pF/m
Velocity of signal propagation	81 %
Signal delay	4.1 ns/m
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	1.95 Ω/km
Outer conductor resistance	0.85 Ω/km
Operating Voltage (at sea level)	≤ 1.05 kVrms
Test voltage (50 Hz/1 min)	≤ 2.1 kVrms
