RG178D/RD178, 50 Ohm, 6 GHz, 200°C, ø2.4 mm, FEP jacket

Name: RG178D/RD178, 50 Ohm, 6 GHz, 200°C, ø2.4 mm, FEP jacket
SKU: 22610061

Product number 22610061

Identifier K_01252_D

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper + Silver plated	Strand-07	0.31 mm
Dielectric	PTFE (Polytetrafluoroethylene)		0.83 mm
Outer conductor	Copper, Silver plated	Braid, 95%	1.33 mm
Outer conductor	Copper, Silver plated	Braid, 92%	1.83 mm
Jacket	FEP (Fluorinated ethylene propylene)	RAL 8015 - br	2.4 mm +/- 0.1 mm	HUBER+SUHNER K 01252 D 50 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Product code	K_01252_D
Cable family	K: RF cables with PTFE/FEP/PFA dielectrics
Available as assembly only	No
Cable group	X1

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 6 GHz
Capacitance	97 pF/m
Velocity of signal propagation	69 %
Signal delay	4.84 ns/m
Screening effectiveness	80 dB at frequency 0.001 GHz ... 6GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	785.2 Ω/km
Operating Voltage (at sea level)	≤ 0.5 kVrms
Test voltage (50 Hz/1 min)	≤ 1 kVrms
