Low-loss, 50 Ohm, 18 GHz, 85°C, ø5.3 mm, PUR jacket

Name: Low-loss, 50 Ohm, 18 GHz, 85°C, ø5.3 mm, PUR jacket
SKU: 22511855
Availability: InStock

Product number 22511855

Identifier S_04212_B

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Wire	1.4 mm - 0.2 mm
Dielectric	SPE (Foamed Polyethylene)		3.8 mm
Outer conductor	Aluminum / PES	longitudinal Foil, 100%	4 mm
Outer conductor	Copper, Tin plated	Braid, 87%	4.5 mm
Jacket	PUR (Polyurethane)	RAL 9005 - bk	5.3 mm +/- 0.2 mm	HUBER+SUHNER S 04212 B 50 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Product code	S_04212_B
Cable family	S: Low loss RF cables with foam PE dielectrics
Available as assembly only	No
Cable group	X9

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 18 GHz
Capacitance	82 pF/m
Velocity of signal propagation	82 %
Signal delay	4.1 ns/m
Screening effectiveness	90 dB at frequency 0.1 GHz ... 18GHz
Insulation resistance	100000000 MΩ*m
Operating Voltage (at sea level)	≤ 0.5 kVrms
Test voltage (50 Hz/1 min)	≤ 1 kVrms
