RG188, 50 Ohm, 3 GHz, 200°C, ø2.6 mm, FEP jacket

Name: RG188, 50 Ohm, 3 GHz, 200°C, ø2.6 mm, FEP jacket
SKU: 22511839

Product number 22511839

Identifier RG_188_A/U-60

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper + Silver plated	Strand-07	0.54 mm
Dielectric	PTFE (Polytetrafluoroethylene)		1.55 mm
Outer conductor	Copper, Silver plated	Braid, 94%	2 mm
Jacket	FEP (Fluorinated ethylene propylene)	RAL 9010 - wh	2.6 mm +/- 0.1 mm	HUBER+SUHNER RG 188 A/U-60 50 Ohm (UL logo) AWM Style 1354 (production order number)

Electrical data

Mechanical data

Environmental data

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 3 GHz
Capacitance	97 pF/m
Velocity of signal propagation	69 %
Signal delay	4.86 ns/m
Screening effectiveness	41 dB at frequency 0.001 GHz ... 1GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	246.05 Ω/km
Operating Voltage (at sea level)	≤ 1.45 kVrms
Voltage Rating UL	30 V
Test voltage (50 Hz/1 min)	≤ 1.7 kVrms
