RG174D alternative, 50 Ohm, 6 GHz, 85°C, ø3.1 mm, PUR jacket

Name: RG174D alternative, 50 Ohm, 6 GHz, 85°C, ø3.1 mm, PUR jacket
SKU: 22511668

Product number 22511668

Identifier G_02212_D-02

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Strand-07, RAL 2001 - or	0.48 mm - 0.1 mm
Dielectric	PE (Polyethylene)		1.5 mm
Outer conductor	Copper, Silver plated	Braid, 95%	2 mm
Outer conductor	Steel, Copper + Silver plated	Braid, 93%	2.5 mm
Jacket	PUR (Polyurethane)	RAL 2001 - or	3.1 mm +/- 0.1 mm	HUBER+SUHNER G 02212 D-02 50 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Product code	G_02212_D-02
Cable family	G: RF cables with PE dielectrics
Available as assembly only	No
Cable group	U4

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 6 GHz
Capacitance	100 pF/m
Velocity of signal propagation	66 %
Signal delay	5.03 ns/m
Screening effectiveness	80 dB at frequency 0.001 GHz ... 1GHz
Insulation resistance	100000000 MΩ*m
Operating Voltage (at sea level)	≤ 1.5 kVrms
Test voltage (50 Hz/1 min)	≤ 3 kVrms
Noise level	20 mV

Operation temperature	-40 °C ... 85 °C
Installation temperature	-20 °C ... 60 °C
Fire characteristics	free of halogenes, acc. standard IEC 60754
