RG223 LSFH, 50 Ohm, 6 GHz, 105°C, ø5.4 mm, RADOX® jacket

Name: RG223 LSFH, 50 Ohm, 6 GHz, 105°C, ø5.4 mm, RADOX® jacket
SKU: 22511592

Product number 22511592

Identifier GX_03272_D-06

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Wire, 96 %, RAL 9005 - bk	0.88 mm - 0.1 mm	HUBER+SUHNER GX 03272 D-06 50 Ohm (production order number)
Dielectric	PEX (Polyethylene cross-linked)		2.95 mm
Outer conductor	Copper, Silver plated	Braid, 96%	3.6 mm
Outer conductor	Copper, Silver plated	Braid, 94%	4.2 mm
Jacket	RADOX	RAL 9005 - bk	5.4 mm +/- 0.1 mm	HUBER+SUHNER GX 03272 D-06 50 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Product code	GX_03272_D-06
Cable family	GX: RF cables with cross-linked PE dielectrics
Available as assembly only	No
Cable group	U9

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 6 GHz
Capacitance	101 pF/m
Velocity of signal propagation	66 %
Signal delay	5.03 ns/m
Screening effectiveness	80 dB at frequency 0.001 GHz ... 6GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	27.7 Ω/km
Operating Voltage (at sea level)	≤ 2.5 kVrms
Test voltage (50 Hz/1 min)	≤ 5 kVrms

Operation temperature	-40 °C ... 105 °C
Installation temperature	-20 °C ... 60 °C
Flame propagation standard	IEC 60332-1
Fire characteristics	free of halogenes, acc. standard IEC 60754
