RG174, 50 Ohm, 1 GHz, 85°C, ø2.8 mm, PVC jacket

Name: RG174, 50 Ohm, 1 GHz, 85°C, ø2.8 mm, PVC jacket
SKU: 22511579
Availability: InStock

Product number 22511579

Identifier RG_174_A/U

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper plated	Strand-07, 87%	0.48 mm - 0.12 mm
Dielectric	PE (Polyethylene)		1.48 mm
Outer conductor	Copper, Tin plated	Braid, 87%	2 mm
Jacket	PVC II (low migration)	RAL 9005 - bk	2.8 mm +/- 0.12 mm	HUBER+SUHNER RG 174 A/U 50 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 1 GHz
Capacitance	101 pF/m
Velocity of signal propagation	66 %
Signal delay	5.03 ns/m
Screening effectiveness	40 dB at frequency 0.0001 GHz ... 1GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	317.3 Ω/km
Outer conductor resistance	41.8 Ω/km
Operating Voltage (at sea level)	≤ 1.5 kVrms
Test voltage (50 Hz/1 min)	≤ 3 kVrms
