RG59, 75 Ohm, 1 GHz, 85°C, ø6.1 mm, PVC jacket

Name: RG59, 75 Ohm, 1 GHz, 85°C, ø6.1 mm, PVC jacket
SKU: 22510368

Product number 22510368

Identifier RG_59_B/U

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Steel, Copper plated	Wire, 93%	0.58 mm - 0.15 mm
Dielectric	PE (Polyethylene)		3.64 mm
Outer conductor	Copper	Braid, 93%	4.5 mm
Jacket	PVC II (low migration)	RAL 9005 - bk	6.1 mm +/- 0.15 mm	HUBER+SUHNER RG 59 B/U 75 Ohm (production order number)

Electrical data

Mechanical data

Environmental data

Impedance	75 Ω +/-1.5Ω
Operating frequency	≤ 1 GHz
Capacitance	67 pF/m
Velocity of signal propagation	66 %
Signal delay	5.07 ns/m
Screening effectiveness	40 dB at frequency 0.0001 GHz ... 1GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	152 Ω/km
Operating Voltage (at sea level)	≤ 3 kVrms
Test voltage (50 Hz/1 min)	≤ 6 kVrms
