RG174 alternative, 50 Ohm, 1 GHz, 85°C, ø2.55 mm, PVC jacket

Name: RG174 alternative, 50 Ohm, 1 GHz, 85°C, ø2.55 mm, PVC jacket
SKU: 22510110
Availability: InStock

Product number 22510110

Identifier G_02232-09

Variation: -

Key features

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper	Strand-07, RAL 7035 - gr	0.49 mm - 0.13 mm
Dielectric	PE (Polyethylene)		1.5 mm
Outer conductor	Copper	Braid, 96%	2 mm
Jacket	PVC (Polyvinyl chloride)	RAL 7035 - gr	2.55 mm +/- 0.13 mm	No print on jacket

Electrical data

Impedance	50 Ω +/-2Ω
Operating frequency	≤ 1 GHz
Capacitance	101 pF/m
Velocity of signal propagation	66 %
Signal delay	5.03 ns/m
Screening effectiveness	40 dB at frequency 0.001 GHz ... 1GHz
Insulation resistance	100000000 MΩ*m
Inner conductor resistance	126.2 Ω/km
Outer conductor resistance	31.6 Ω/km
Operating Voltage (at sea level)	≤ 1.5 kVrms
Test voltage (50 Hz/1 min)	≤ 3 kVrms
Noise level	10 mV

Mechanical data

Environmental data

Product code	G_02232-09
Cable family	G: RF cables with PE dielectrics
Available as assembly only	No
Cable group	U2
