MLUM 8F, SM, 1x Q-ODC-12 input, 4x Q-ODC-2

Name: MLUM 8F, SM, 1x Q-ODC-12 input, 4x Q-ODC-2
SKU: 85142329
Availability: InStock

Product number 85142329

Identifier MLUM-J-10-08-0-NNNNQOR9-4QOU1-000-SS

Variation: -

Key features

How to use it

General data

Side A / Left

Fiber Optic Cable

Cable Description	Multifiber bundle cable
Fiber quantity	12
Fiber type	E9/125A2
CPR class	Dca-s1a,d0,a1
Strain relief	aramide yarn
Steel armoring	LSFH
Outer jacket diameter	3mm
Outer jacket material	LSFH
Tensile strength during installation	500 N
Tensile strength in service	200 N
Min. bending radius during installation	20 mm
Min. bending radius in service	20 mm
Fire propagation standard	IEC 60332-1-2

Product family	MASTERLINE Ultimate Micro
Application Area	Outdoor
Fiber quantity	8
UV resistance	EN ISO 4892-2
Impact resistance	IK10
Ingress protection (IP Rating)	IP68
Dimensions (LxWxH)	116mm x 77mm x 117mm
Installation temperature	-10 °C ... 50 °C
Operation temperature	-40 °C ... 75 °C

Entry Port	1x Q-ODC-12 socket
Exit port	4x Q-ODC-2 socket
