High-flexible, Low-loss, 50 Ohm, 6 GHz, 85°C, ø10.25 mm, TPU jacket
Product number 85089191
Identifier SPUMA_400-RS-FR
Variation: -
Product code |
|
Cable family |
|
Available as assembly only |
|
Cable group |
|
General Information
- Halogen free cable with standard dimensions
- Low smoke
- Ozone, UV and weathering resistance
- RS - Rotary Swaged centre conductor
- Railway qualified
Key features
- Railway
How to use it
Specifications
Component | Material | Detail | Diameter | Cable jacket print |
---|---|---|---|---|
Centre conductor | Copper | Strand, Rotary swaged | 2.74 mm | |
Dielectric | SPE (Foamed Polyethylene) | 7.24 mm | ||
Outer conductor | Aluminum / PES | longitudinal Foil, 100% | 7.4 mm | |
Outer conductor | Copper, Tin plated | Braid, 91% | 8.15 mm | |
TPU (Urethane TPE) | RAL 9005 - bk | 10.25 mm +/- 0.1 mm | HUBER+SUHNER SPUMA 400-RS-FR 50 Ohm (production order number) |
Impedance |
|
Operating frequency |
|
Capacitance |
|
Inductance |
|
Velocity of signal propagation |
|
Signal delay |
|
Screening effectiveness |
|
Insulation resistance |
|
Inner conductor resistance |
|
Outer conductor resistance |
|
Operating Voltage (at sea level) |
|
Test voltage (50 Hz/1 min) |
|
Weight |
|
Static bending radius |
|
Repeated bending radius |
|
Operation temperature |
|
Installation temperature |
|
Flame propagation standard |
|
Fire characteristics |
|
Smoke test |
|
UV resistance |
|
