Semi-rigid, 50 Ohm, 40 GHz, 125°C, ø2.95 mm, Copper/Tin plated

Product number 22830073

Identifier SR_118_TP_3M

Variation 3 meter

Choose a variant

3 meter

General Information

Key features

Formstable cable for precise, time saving installations
Excellent RF screening performance
Highly efficient RF signal distribution

Specifications

Construction

Component	Material	Detail	Diameter	Cable jacket print
Centre conductor	Copper, Silver plated	Wire	0.81 mm
Dielectric	PTFE-LD		2.41 mm
Outer conductor	Copper, Tin plated	Tube, 100%	2.95 mm

Electrical data

Mechanical data

Environmental data

Material compliance ROHS

Material compliance REACH

Semi-rigid, 50 Ohm, 40 GHz, 125°C, ø2.95 mm, Copper/Tin plated

Related products

Suitable connectors

COAXIAL CONNECTOR, SK, 50 Ohm, Straight bulkhead cable jack (female)

COAXIAL CONNECTOR, SK, 50 Ohm, Straight bulkhead cable jack (female)

84016419

24_SK-50-2-55/1--_NE

Single packaging

COAXIAL CONNECTOR, SK, 50 Ohm, Straight cable jack (female)

COAXIAL CONNECTOR, SK, 50 Ohm, Straight cable jack (female)

22645973

21_SK-50-2-51/199_NE

Single packaging

COAXIAL CONNECTOR, SK, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, SK, 50 Ohm, Straight cable plug (male)

22645972

11_SK-50-2-51/119_NE

Single packaging

COAXIAL CONNECTOR, SK, 50 Ohm, Straight cable plug (male)

COAXIAL CONNECTOR, SK, 50 Ohm, Straight cable plug (male)

22658705

11_SK-50-2-51/119_NH

Bulk packaging
