Vehicles overview

Directional railway inter-carriage antennas for high-throughput data transmission between train carriages which require no manual configuration during train operation.

• Throughput speeds of more than 400 Mbit/s
• Specifically designed radiation pattern provides robust and secure link
• Once installed, no physical configuration or maintenance is required
• Norms: Railway EN 50155, Railway EN 45545-2

Omni-directional SISO railway in-carriage and trackside antenna family for all types of trains. Designed to meet the special requirements of railway applications including environmental and fire certifications.

• Railway in-carriage and fixed infrastructure omni-directional antennas
• Covers services for WiFi 2.4 and 5 GHz bands
• Single hole mounting and compact form factor
• Certified for Railway standarsd EN 50155 and EN 45545-2
• NFPA-130 Variants available

Railway in-carriage omni-directional antennas

• Allows up to 4x4 MIMO configuration
• Covers services for WiFi 2.4 and 5 GHz bands
• Single-hole mounting
• Certified for EN 50155, EN 45545-2 and NFPA-130 Railway Standards
• Omni-directional MIMO railway in-carriage antenna family for all types of trains. Designed to meet the special requirements of railway applications including environmental and fire certifications.

Omni-directional MIMO railway in-carriage antenna family are suitable for all types of trains. Designed to meet the special requirements of railway applications including environmental and fire certifications.

• Railway in-carriage omni-directional antenna
• Available in 3x3 and 6x6 MIMO configurations
• Covers services for Wi-Fi 2.4, 5 and 6 GHz bands
• Supports the new Wi-Fi 6E frequency bands
• Flush wall/ceiling mounting and compact form factor
• Certified for Railway standards EN 50155, EN 45545-2 and NFPA-130

Omni-directional MIMO railway in-carriage antenna + access point suitable for all types of trains. Designed to meet the special requirements of railway applications including environmental and fire certifications.

• Railway in-carriage omni-directional antenna + access point
• Power and data provided via a single PoE+ M12 X-Pol receptable
• Contains 2x 3x3 MIMO Wi-Fi 5 radios connected to 6 antenna elements
• Up to 128 clients per radio
• Flush wall/ceiling mounting and compact form factor
• Certified for Railway standards EN 50155, EN 45545-2 and NFPA-130

The first-of-its-kind omni-directional, broadband rooftop antenna has an integrated connected compute module, cellular radios, Wi-Fi access point and GNSS receiver. It provides power and data via a single ethernet cable and is designed to meet the special requirements of railway applications, including high current and high voltage protection.

• Railway rooftop omni-directional antenna with integrated compute module and radios.
• Power and Data provided via a single PoE+ M12 X-Pol cable assembly.
• 4x4 MIMO 4G and 5G integrated radio options connected to separate antenna elements.
• 2x2 MIMO Wi-Fi access point connected to separate antenna elements.
• L1 Multibands GNSS antenna and receiver
• Certified for Railway standards EN 50155, EN 45545-2 and NFPA-130

Directional railway rooftop antenna family for all types of trains. Designed to meet the special requirements of railway applications including high current and high voltage protection.

• Railway roof-top directional antennas
• Vertically polarized uni-directional and bi-directional variants
• Covers services for WiFi 2.4 and 5 GHz bands
• High directional gain from 11 to 14 dBi
• Certified for EN 50155 & EN 45545-2 Railway Standards

Omni-directional railway roof-top antenna family for all types of trains. Designed to meet the special requirements of railway applications including high current and high voltage protection.

• Omni-directional roof-top railway antennas
• SISO Confirguration
• Covers services for VHF, TETRA, GSM-R, 2G/3G/4G/5G cellular and WiFi 2.4/5 GHz bands and GNSS.
• Certified for EN 50155 & EN 45545-2 Railway Standards

Omni-directional broadband MIMO and SISO rooftop antennas for all types of trains. Ultra low profile design with a maximum height of only 40mm. Designed to meet the special requirements of railway applications including high current and high voltage protection.

• Omni-directional roof-top railway antennas
• SISO and MIMO (2x2) Options available
• Covers services for GSM-R, 2G/3G/4G/5G cellular and Wi- Fi 2.4/5/6 GHz bands.
• Certified for EN 50155, EN 45545-2 & NFPA-130 Railway Standards
• Embedded GNSS options with or without integrated LNA

Omni-directional MIMO broadband railway rooftop antennas for all types of trains. Designed to meet the special requirements of railway applications including high current and high voltage protection

• Omni-directional roof-top railway antennas
• MIMO Configuration (2x2)
• Covers services for GSM-R, 2G/3G/4G/5G cellular and WiFi 2.4/5 GHz bands
• Optional embedded multi-band or dual-band GNSS module
• Certified for EN 50155 & EN 45545-2 Railway Standards
• NFPA-130 Variants available

Dual-Polarised, Omni-directional Cellular 2x2 and 4x4 MIMO rooftop antennas are designed for wireless applications to meet special requirements of railway applications including high current and high voltage protection.

• Patent Pending Omni-directional Dual-Polarised Technology for maximum data rates.
• MIMO configurations in 2x2 and 4x4
• Cover services for 2G/3G/4G/5G cellular as well as GNSS (including dual band L1+L2+L5)
• Rugged design, meets EN 50155 Railway Standard
• Fire retardant according to EN 45545-2 and NFPA-130
• Low height requirements: 90 mm total

Omni-directional broadband 4x4 MIMO rooftop antennas are designed for wireless applications to meet special requirements of railway applications including high current and high voltage protection.

• Omni-directional rooftop railway antennas
• MIMO configurations in 4x4, 2x 4x4
• Cover services for 2G/3G/4G/5G cellular and Wi-Fi 6E bands as well as GNSS (including dual band L1+L2+L5)
• Rugged design, meets EN 50155 Railway Standard
• Fire retardant according to EN 45545-2 and NFPA-130
• Low height requirements: 90 mm total

The SENCITY® Road rooftop antennas are developed for buses, trucks and heavy duty vehicles. The portfolio of antennas offers bespoke solutions with different combinations of radiating elements efficiently designed to fit into a single compact housing.

• Up to 4 antenna elements in one housing
• Single-hole mounting
• 82 mm height
• Frequency bands 380 MHz to 7.125 GHz
• Supports up to 5G and up to Wi-Fi 6E
• Supports TETRA
• Stick antenna options for cellular, TETRA, VHF, FM, etc.
• Embedded GNSS antenna with integrated low-noise amplifier
• ISO 16750, ECE-R118 compliant
• Works without metal ground plane

The SENCITY® Road IC (in-carriage) antennas are designed for seamless and outstanding in-carriage connectivity. These antennas have several radiating elements stored in one compact housing and allow FAKRA or SMA connection.

• Supports MIMO for Wi-Fi
• Up to 6 Wi-Fi elements
• Ready for Wi-Fi 6E
• Single-hole mounting
• Low profile
• ISO 16750, ECE-R118 compliant
• Works without metal ground plane
• FAKRA and SMA connector available

SENCITY® Road MIMO antennas offer support for MIMO systems either by use of several radiating elements within one common housing or by installing several antennas spaced from each other for an optimised performance.

• Up to 5 antenna radiators in one housing
• 2x2 MIMO for Cellular
• 2x2 or 3x3 MIMO for WiFi
• Embedded GNSS antenna with integrated low-noise amplifier
• Frequency bands 694 MHz to 7.125 GHz
• Supports 5G and Wi-Fi 6E
• Single-hole mounting
• 98 mm height
• ISO 16750, ECE-R118 compliant
• Works without metal ground plane

The SENCITY® Road MULTI is designed for 4x4 MIMO operation in cellular, 8x8 MIMO in Wi-Fi networks. It also offers a variety of combinations of up to 9 radiators within one housing and comes with an GNSS option for L1, L2, L5 operation. It meets the special requirements for any kind of installation on buses, trucks or any other type of commercial vehicle.

• Rugged multi-element and multi-band rooftop antenna
• Supports 2G/3G/4G/5G cellular, Wi-Fi 2.4/5 GHz, Wi-Fi 6E and Dual Band GNSS (Beidou, Galileo, GPS, Glonass).
• Up to 9 separate ports for 4x4 cellular MIMO and 4x4 Wi-Fi MIMO plus GNSS.
• Frequency bands 380 MHz to 7.125 GHz
• Supports up to 5G and up to Wi-Fi 6E
• Comes with Dual Band GNSS (L1, L2, L5)
• Meets ISO16750 automotive standard.
• Compliant to ECE-R118.
• Single-hole mounting, easy cabling feed-through.

This SENCITY® Road antenna is in a PUCK form factor and designed for connection in SISO applications in 400 MHz bands / TETRA.

• Single-hole mounting
• 70 mm height
• Frequency bands 406-428 MHz and 440-470 MHz
• Supports TETRA
• Meets EN 50155 standard
• ECE-R118 approved

The SENCITY® Road VHF antenna is designed for applications in the 2-meter band.

• 3-hole installation
• Frequency bands from 143 MHz to 178 MHz
• Meets EN 50155 standard
• Fire retardant according to EN 45545-2
• ECE-R118 approved

The SENCITY® Road Low Profile provides the best low profile solution for commercial vehicles and comes with basic cellular, Wi-Fi and GNSS functionalities. Combinations of Cellular MIMO with Wi-Fi and GNSS are offered as well.

• Up to 3 antenna elements in one housing
• Single-hole mounting
• Low profile, Only 33mm in height
• Frequency bands 694 MHz to 7.125 GHz
• Supports up to 5G and up to Wi-Fi 6E
• Embedded GNSS antenna with integrated low-noise amplifier
• Extremly ruggedized
• ISO 16750, ECE-R118 compliant

Directional high gain WLAN / WiFi antenna for railway trackside and tunnel applications.

• Directional yagi antenna for railway trackside and tunnel applications
• Gain 14 dBi
• Configuration SiSo
• Norms: Railway EN 50125, Railway EN 45545-2

Compact directional railway in-carriage antenna family for all types of trains. Designed to meet the special requirements of railway applications including environmental and fire certifications.

• Railway in-carriage directional antennas
• Covers services for Wi-Fi 2.4 and 5 GHz bands
• Various mounting brackets available
• Certified for Railway standards EN 50155, EN 45545-2 and NFPA-130

The SENCITY® Tram rooftop antennas are developed to meet the unique requirements for light rail vehicles such as trams and metros. The portfolio of antennas offers railway certified solutions with different combinations of radiating elements efficiently designed to fit into a single compact housing.

• Up to 4 antenna elements in one housing
• Single-hole mounting
• 82 mm height
• Frequency bands 380 MHz to 7.125 GHz
• Supports up to 5G and up to Wi-Fi 6E
• Supports TETRA
• Stick antenna options for cellular, TETRA, VHF, FM, etc.
• Embedded GNSS antenna with integrated low-noise amplifier
• EN50155, EN45545-2 compliant
• Works without metal ground plane

SENCITY® Tram MIMO antennas offer support for MIMO systems either by use of several radiating elements within one common housing or by installing several antennas spaced from each other for an optimised performance.

• Up to 4 antenna elements in one housing
• Up to 5 antenna radiators in one housing
• 2x2 MIMO for Cellular
• 2x2 or 3x3 MIMO for Wi-Fi
• Embedded GNSS antenna with integrated low-noise amplifier
• Frequency bands 694 MHz to 7.125 GHz
• Supports 5G and Wi-Fi 6E
• Single-hole mounting
• 98 mm height
• EN50155, EN45545-2 compliant
• Works without metal ground plane

SENCITY® Tram MULTI antennas offer support for 4x4 MIMO systems with up to 9 radiators in one housing for a variety of combinations of Wi-Fi, cellular and GNSS options. It meets the special requirements for any kind of installation on light rail or tram vehicles.

• Up to 9 antenna radiators in one housing
• 4x4 MIMO for Cellular plus 4x4 WiFi
• 2x2 Tetra/Cellular plus 4x4 WiFi
• 8x8 WiFi
• Plus embedded (Dual Band) GNSS antenna with integrated low-noise amplifier
• Frequency bands 380 MHz to 7.125 GHz
• Supports 5G and Wi-Fi 6E
• Single-hole mounting
• 62 mm height
• EN50155, EN45545-2 compliant
• IK10 impact resistance
• Works without metal ground plane
